Industry applications: The main market applications for item-level item identification, such as clothing, leather goods luggage, alcohol, electricity and other industries, access management, item-level labels and box label comparison, product inventory and so on.
Brand:
JTSPEEDWORKItem NO.:
JT-R203Product Origin:
Shenzhen,China
| Main Specification | Electronic Control | Domestic PLC | ||
| Model Code | ROV-R203 | Antenna | 4 Groups of 8dbi Antennas | |
| Air Interface Protocol | EPC Global Class1 Gen2/ISO 18000-6C | Load Capacity | 50kg | |
| RFID Frequency | 902.75MHz~927.25MHz, channel spacing 500kHz | Adjustable Speed of Conveyor | 0-30m/min | |
| RFID Frequency Mode | Fixed Frequency/Frequency Hopping, 10 Frequency Hopping Points | Reversible or Not | Reversible Conveyor | |
| Reader | Domestic (Imported R2000 chip) | Opening Speed | 3 Seconds | |
| Reading Efficiency | 3~5 seconds | Dock With Production Line or Not | No | |
| Reading Mode | Motionless | |||
| Reader Output Power | 1-30dBm | |||
| Conveyor Speed | Up to 30m/min | Physical Environment | ||
| Conveyor Load Bearing | Up to 50KG | Overall Size (mm) | 2640 (length)x1120(width)x 1700 (height) | |
| Efficiency | 5~6 Boxes/min | Inner Size (mm) | 1200 (length)x 880 (width)x 780 (height) | |
| Number of Tag Reading | 200+ pcs per box (Depending on the Tag Performance) | Maximum Passable Size of Box (mm) | 800 (length)x 800 (width) x 600 (height) | |
| Operating Mode | Interval T cycle / Continuous Operation / External Trigger | Total Weight | About 350KG | |
| Screen | 15.6-inch Resistive Touch (Embedded) | Operating Temperature | -20℃~60℃ | |
| Programmable Controller | Domestic | Storage temperature | -10℃~60℃ | |
| Electronic Control System | With Domestic PLC | Operating Humidity | 20~95%(non-condensing) | |
| Industrial Computer | J1900/4GB | Work Voltage | 220VAC(+10%)50+3HZ | |
| Photoelectric Switch | 4 Groups/Imported | Power | 350W | |
| Automatic Conveyor Belt | One Conveyor/ Independent Power Control | Enclosure Material | Spray-paintCarbon Steel | |
| Material of Conveyor Belt | Leather belt | Shielding Performance | 30~50CM | |
Product Characteristics
♦High detection and identification efficiency, 3~5 seconds can read 200+ electronic tags in a single box;
♦Professional motion control and mechanical design technology, fully solve the problem of label reading leakage;
♦Tight electromagnetic shielding design and RF optimization, can eliminate the harm of RF radiation on the human body, at the same time the label reading accuracy of 100% (depending on the quality of the label, read the environment);
♦Industrial control computer software can control the whole machine function, monitor all the equipment running status, the external at the same time with mechanical keys, convenient for operators to control the equipment working status at any time;
♦Industrial roller conveying line design, fully solve the problem of conveying line body offset maintenance;
♦The channel is equipped with access doors on both sides, which is convenient for equipment maintenance;
♦Support the expansion of abnormal sorting module, to meet the needs of different users, and support the secondary development of application software for customers.
