Industry applications: The main market applications for item-level item identification, such as clothing, leather goods luggage, alcohol, electricity and other industries, access management, item-level labels and box label comparison, product inventory and so on.
Brand:
JTSPEEDWORKItem NO.:
JT-R120Product Origin:
Shenzhen,China
| Main Specification | Electronic Control | With Domestic PLC | ||
| Model Code | ROV-R120 | Antenna | 4 Groups of 9dbi Antennas | |
| Air Interface Protocol | EPC Global Class1 Gen2/ISO 18000-6C | Load Capacity | 50kg | |
| RFID Frequency | 902.75MHz ~ 927.25MHz, Channel Spacing is 500kHz | Adjustable Speed of Conveyor | 0-40m/min | |
| RFID Frequency Mode | Fixed Frequency / Frequency Hopping, 10 Frequency Hopping Points | Reversible or Not | Reversible Conveyor | |
| Reader | Domestic (Imported R2000 chip) | Opening Speed | 1 Second | |
| Reader Output Power | 1-30±1dBm | Dock With Production Line or Not | No | |
| Conveyor Speed | Up to 40m / min | Physical Environment | ||
| Conveyor Load Bearing | Up to 50KG | Tunnel size (mm) | 950 (length) × 1100 (width) × 1660ight) | |
| Efficiency | Manual | Ball Transfer Table Size (mm) | 1600(length) × 600 (width) × 700 (height) | |
| Automatic Conveyor Belt | One Conveyor / Independent Power Control | Maximum Passable Size of Box (mm) | 700(length) × 700 (width) × 700 (height) | |
| Material of Conveyor Belt | Leather Belt | Total Weight | About 240KG | |
| Screen Door | Shutter Door (Electric) | Operating Temperature | -20℃~60℃ | |
| Number of Tag Reading | 200+pcs | Storage Temperature | -10℃~60℃ | |
| Reading Efficiency | 3~5 Seconds | Operating Humidity | 20~95%(non-condensing) | |
| Reading Mode | Motionless | Work Voltage | 220VAC（±10%）50±3HZ | |
| Operating Mode | Interval T Cycle / Continuous Work / External Trigger | Power | 350W | |
| Screen | 15.6-inch Resistive Touch Screen | Enclosure Material | Spray-paint Carbon Steel | |
| Industrial Computer | J1900/4GB | Shielding Performance | 5~10CM | |
| Photoelec tricSwitch | 2Groups/Imported | |||
Product Characteristics
♦High detection and identification efficiency, it only takes about 3~5 seconds to read 200+pcs;
♦Professional motion control and mechanical design technology, fully solve the problem of label miss-reading;
♦Tight electromagnetic shielding design and RF optimization, can eliminate the harm of RF radiation on the human body, at the same time the tag reading accuracy of 100% (depending on the quality of the tag, reading environment);
♦ Can change the imported or domestic RFID reader, to meet the needs of different users, to support customers to secondary development of application software.
Protect your JTSPEEDWORK devices for constant peak performance with these recommended maintenance plans. Device uptime, confidence, and savings — that's what you get with JTSPEEDWORK maintenance plans. You protect business-critical devices and eliminate disruptions and unplanned repair expenses.
