Brand:
JTSPEEDWORKItem NO.:
JT-L201
| Item No. | JT-L201 | ||||
| Main Specifications | Operating Environment | ||||
| Air Interface Protocol | Total Size (mm) |
4100 (length) × 1120 (width) × 1900 (height) （The width of the lifting arm is not calculated） |
|||
| EPC Global Class1 Gen2/ISO 18000-6C | Inner size(mm) | 1500 (length) × 800 (width) × 880 (height) | |||
| RFID Frequency | Front/Rear Conveyor Size (mm) | 1200 (length) × 960 (width) × 580 (height) | |||
| 902MHz~928MHz | Maximum Passable Size of Box(mm) | 1100 (length) × 800 (width) × 800 (height) | |||
| RFID Frequency Mode | Programmable Controller | Domestic | |||
| Fixed Frequency / Frequency Hopping, 10 Frequency Hopping Points | Weighing Module | Optional | |||
| Reader Output Power | Sorting Module | Optional | |||
| 5-33dBm | Total Weight | About 550KG | |||
| Conveyor Speed | Operating Temperature | -20℃– 60℃ | |||
| Up to 40m/min | Storage Temperature | -10℃~60℃ | |||
| Efficiency | Operating Humidity | 20 – 95% (non-condensing) | |||
| 8~10boxes/min | Work Voltage | 220VAC（±10%）50±3HZ | |||
| Number of Tag Reading | Power | 1000W | |||
| 600+pcs | Enclosure Material | Spray-paint Carbon Steel | |||
| Reader | Shielding Performance | 5-10CM | |||
| Imported (Impinj-R420) | |||||
Previous:
JT-L401 RFID Tray-type Tunnel MachineNext:
JT-R101TC RFID Tunnel Reader Device Cargo Inventory StationIf you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
