Industry applications: The main market applications for item-level item identification, such as clothing, leather goods luggage, alcohol, electricity and other industries, access management, item-level labels and box label comparison, product inventory and so on.
Brand:
JTSPEEDWORKItem NO.:
JT-R202Shipping Port:
ShenzhenCommunication Interface
Operating system
Working frequency:
Protocol:
RF chip:
Antenna gain:
| Main Specification | ||||
| Model Code | ROV-R202 | Electronic Control | Domestic PLC | |
| Air Interface Protocol | EPC Global Class1 Gen2/ISO 18000-6C | Antenna | 4 Groups of 8dBi Antennas | |
| RFID Frequency | 902.75MHz~927.25MHz, channel spacing 500kHz | Load Capacity | 50KG | |
| RFID Frequency Mode | Fixed Frequency/Frequency hopping, 10 Frequency Hopping Points | Adjustable Speed of Conveyor | 0-30m/min | |
| Reader | Domestic (Imported R2000 chip) | Reversible or Not | Reversible Conveyor | |
| Reader Output Power | 1-30dBm | Opening Speed | 3 Seconds | |
| Conveyor Speed | Up to 30m/min | Dock With Production Line or Not | Yes | |
| Conveyor Load Bearing | Up to 50KG | Physical Environment | ||
| Efficiency | 5~6 Boxes/min | Overall Size (mm) | 3340 (length) × 1120 (width) × 1600 (height) | |
| Number of Tag Reading | 200+pcs | Inner Size(mm) | 1200 (length) × 880 (width) × 780 (height) | |
| Reading Efficiency | 3~5 seconds | Front/Rear Conveyor (mm) | 800 (length) × 960 (width) × 500 (height) | |
| Reading Mode | Motion/Motionless | Maximum Passable Size of Box (mm) | 800 (length) × 800 (width) × 600 (height) | |
| Operating Mode | Interval T cycle / Continuous Operation / External Trigger | Total Weight | About 500KG | |
| Screen | 15.6-inch Resistive Touch Screen (Embedded) | Operating temperature | -20℃~60℃ | |
| Programmable Controller | Domestic | Storage temperature | -10℃~60℃ | |
| Electronic Control System | With Domestic PLC | Operating humidity | 20~95%(non-condensing) | |
| Industrial Computer | J1900/4GB | Work Voltage | 220VAC（±10%）50±3HZ | |
| PhotoelectricSwitch | 8Groups/Imported | Power | 1000W | |
| Automatic Conveyor Belt | ThreeConveyors/IndependentPowerControl | Enclosure Material | Spray-paint Carbon Steel | |
| Material of Conveyor Belt | Leather belt | Shielding Performance | 5~10CM | |
Product Characteristics
♦High detection and identification efficiency, it takes only 3~5 seconds to read 200+ electronic tags in a single box;
♦Professional motion control and mechanical design technology, fully solve the problem of label miss-reading;
♦Tight electromagnetic shielding design and RF optimization, can eliminate the harm of RF radiation on the human body, at the same time the label reading accuracy of 100% (depending on the quality of the label, read the environment);
♦Industrial control computer software can control the function of the whole machine, monitor all the equipment running status, the external at the same time with mechanical keys, convenient for operators to control the working status of the equipment at any time;
♦Industrial rolling egg conveying line design, fully solve the problem of conveying line body offset maintenance;
♦The channel is equipped with access doors on both sides, which is convenient for equipment maintenance;
♦Support the expansion of abnormal sorting module, to meet different user needs, and support customers to carry out secondary development of application software.
