Industry application: The main market application is for item-level item identification, such as in and out of warehouse management, item-level label and box label comparison, product inventory in apparel, laundry, liquor, electricity and other industries.
Brand:
JTSPEEDWORKItem NO.:
JT-R101XShipping Port:
ShenzhenCommunication Interface
Operating system
Working frequency:
Protocol:
RF chip:
Antenna gain:
Main Specifications
Physical Environm
Model Code
JT-R101X
Overall Size (mm)
1150 (length) × 1
Air Interface Protocol
EPC Global Class1 Gen2/ISO 18000-6C
Inner Size (mm)
890 (length) × 80
RFID Frequency
902.75MHz~927.25MHz, Channel Spacing 500kHz
Maximum Passable Size of Box (mm)
850 (length) × 73
Reader
Domestic (Imported R2000 chip)
Total Weight
About 200KG
Reader Output Power
1-30±1dBm
Operating Temperature
-20℃~60℃
Number of Tag Reading
200+pcs
Storage Temperature
-10℃~60℃
Reading Efficiency
3~5 Seconds
Operating Humidity
20~95%(Non-co
Reading Mode
Motionless
Work Voltage
220VAC（±10%
Operating Mode
Interval T Cycle / Continuous Operation / External Trigger
Power
150W
Screen
15.6-inch Resistive Touch Screen (Embedded)
Enclosure Material
Spray-paint Carb
Industrial Computer
J1900/4GB
ShieldingPerformance
10~30CM
Antenna
4 Groups of 8dbi Antennas
Load Capacity
200 KG
Opening Speed
Manual
Product Characteristics
♦High detection and identification efficiency, it only takes 3~5 seconds to read 200+ electronic tags;
♦Professional antenna mechanical design technology, fully solve the problem of label reading leakage;
♦Tight electromagnetic shielding design and RF optimization, can eliminate the harm of RF radiation on the human body, at the same time, tag reading accuracy of 100% (depending on the quality of tags, reading environment);
♦ Can change the imported or domestic RFID reader, to meet the needs of different users, to support the secondary development of customer application software.
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
