Industry application: The main market application is for item-level item identification, such as in and out of warehouse management, item-level label and box label comparison, product inventory in apparel, laundry, liquor, electricity and other industries.
Brand:
JTSPEEDWORKItem NO.:
JT-R101Product Origin:
Shenzhen,China
| Main Specification | Physical Environment | |||
| Model Code | JT-R101 | Overall Size (mm) | 1326 (length) × 1200 (width) × 1600 (height) | |
| Air Interface Protocol | EPC Global Class1 Gen2/ISO 18000-6C | Internal Size (mm) | 1130 (length) × 980 (width) × 1250 (height) | |
| RFID Frequency | 902.75MHz~927.25MHz, Channel Spacing 500kHz | Screen Door | Shutter Door (Electric) | |
| Reader | Domestic（Imported R2000 Chip） | Maximum Passable Size of Box (mm) | 1100 (length) × 950 (width) × 1200 (height) | |
| Reader Output Power | 1~30±1dBm | Total Weight | About 250KG | |
| Number of Tag Reading | 200+pcs | Operating Temperature | -20℃~ 60℃ | |
| Reading Efficiency | 3~5 Seconds | Storage Temperature | -10℃~60℃ | |
| Reading Mode | Motionless | Operating Humidity | 20 ~95% (Non-condensing) | |
| Operating Mode | Interval T Cycle / Continuous Operation / External Trigger | Work Voltage | 220VAC（±10%）50±3HZ | |
| Screen | 15.6-inch Resistive Touch Screen (Embedded) | Power | 350W | |
| Programmable Controller | Domestic | Enclosure Material | Spray-paint Carbon Steel | |
| Electric Control System | With Domestic PLC | Shielding Performance | 5~10CM | |
| Industrial Computer | J1900/4GB | |||
| Antenna | 4 Groups of 8dbi Antennas | |||
| Load Capacity | Depending on the Cart | |||
| Opening Speed | 1-2 Seconds | |||
| Efficiency | Manual | |||
Product Characteristics
♦High detection and identification efficiency, 3~5 seconds can read 200+ electronic tags in a single box;
♦Professional antenna mechanical design technology, fully solve the problem of label leakage;
♦Tight electromagnetic shielding design and RF optimization, can eliminate RF radiation damage to human body, at the same time the label reading accuracy of 100% (depending on the quality of the label, read the environment);
♦Automatic roll-up door design, can realize semi-automatic identification of field applications;
♦ Can change the physical door to adapt to a variety of scene applications;
♦Imported or domestic RFID reader can be changed to meet the needs of different users, to support customers to carry out secondary development of application software.
