Feature:     JT-1288 is a high-performance single-channel integrated RFID reader. Using self-developed high-perfor-mance RFID modules based on Impinj E710 chips, and working together with integrated awesome 10dBilinear polarized antenna. The reader supports RS232, RJ45 ,WiFi,4 GPRS communication interfaces. Thewhole series of products have a unified protocol and SDK. You only need to develop our products onceto connect with all our RFID readers.JT-1288 is applicable widely in warehousing, archives management,library management, banking, production line management and other fields. Support RS232,RJ45,WiFi,4G remote online firmware upgrade Support MQTT protocol Specification: Item No. JT-1288 Physical parameters Antenna Dimensions 420(L)*240(W)*50(H)mm 10dBi linear polarized antenna Net weight 1.3Kg Material ABS & aluminum alloy Power Supply Input Voltage DC 12-24V /3A RFID Parameters Peak current 500mA Air Protocol EPC global Gen2(ISO18000-6C) User Environment Working frequency Operating Temp -40 ℃ to 75 ℃ 865-868 / 920-925 / 902-928 MHz ( custom-design for frequency band ) Storage Temp -40 ℃ to 85 ℃ RF power Humidity 5-90% non-condensing (+25° C ) 13~33dBm(adjustable) Chip Reading Performance Impinj E710 Reading distance I/O Up to 15m(relate to tag and environment) 1 trigger input or 2 relay outputs (customized) Model Type Notification JT-1288B RS232,TCP/IP(PoE optional) LED indicator,buzzer JT-1288W RS232,TCP/IP,WiFi RSSI JT-1288G RS232,TCP/IP, 4 GPRS Supported Consumption Datasheet Average power consumption<10W Baud rate SDK 115200 bps (default) Demo&C++,C#,JAVA,Android SDK JTSPEEDWORK Maintenance Plans. /* 全局样式 */ body { font-family: 'Arial', sans-serif; margin: 0; padding: 0; background-color: #f8f9fa; color: #444f5a; } /* 主容器 */ .dna-container { max-width: 1000px; margin: 40px auto; padding: 30px; background-color: #F4FFF8; border-radius: 8px; box-shadow: 0 4px 12px rgba(0, 0, 0, 0.1); text-align: center; } /* 标题样式 */ .dna-title { color: #4D4847; font-size: 28px; font-weight: bold; margin-bottom: 20px; text-align: center; position: relative; padding-bottom: 15px; } .dna-title:after { content: ""; position: absolute; bottom: 0; left: 50%; transform: translateX(-50%); width: 80px; height: 3px; background-color: #4D4847; } /* 正文段落，仅影响 p 标签 */ p.dna-content { font-size: 16px; line-height: 1.6; margin: 0 auto 30px; color: #4D4847; max-width: 800px; text-align: center; } /* 表格内文字颜色不受 .dna-content 段落控制 */ .dna-content table, .dna-content th, .dna-content td { color: initial; } /* 按钮样式 */ .learn-more-btn { display: inline-block; padding: 12px 30px; background-color: #52616b; color: white; text-decoration: none; font-weight: bold; border-radius: 4px; transition: all 0.3s ease; text-transform: uppercase; letter-spacing: 1px; font-size: 14px; border: 2px solid #ffffff; cursor: pointer; } .learn-more-btn:hover { background-color: transparent; color: #0066cc; border-color: #52616b; } /* 响应式设计 */ @media (max-width: 768px) { .dna-container { margin: 20px; padding: 20px; } .dna-title { font-size: 24px; } p.dna-content { font-size: 15px; max-width: 100%; } } JTSPEEDWORK Maintenance Plans. Protect your JTSPEEDWORK devices for constant peak performance with these recommended maintenance plans. Device uptime, confidence, and savings — that's what you get with JTSPEEDWORK maintenance plans. You protect business-critical devices and eliminate disruptions and unplanned repair expenses. LEARN MORE

Item No. JT-1380 Physical Parameters Antenna Dimensions 208(L) *208(W) * 46(H)mm 8dBi circularly polarized antenna (built-in) Net weight 660g Material ABS & aluminum alloy Power Supply Input Voltage DC 9-36V /3A RFID Parameters Air Protocol EPC global Gen2(ISO18000-6C) User Environment Working frequency Operating Temp. -40 ℃ to 75 ℃ 865-868 / 920-925 / 902-928 MHz ( custom-design for frequency band ) Storage Temp. -40 ℃ to 85 ℃ RF power Humidity 5-90% non-condensing (+25° C ) 13~33dBm Work mode Reading Performance Master-slave, timing,trigger mode Reading distance I/O Up to 3m(relate to tag and environment) 1 trigger input or 2 relay outputs (customized) Model Type Notification JT-1380B RS232, TCP /IP(PoE optional) LED indicator,buzzer JT-1380W RS232, TCP /IP,Wi-Fi RF chip JT-1380G RS232,TCP /IP,4 GPRS Impinj E710 Datasheet Reading rate >900 times/sec SDK C# , Java , C++ JTSPEEDWORK Maintenance Plans. /* 全局样式 */ body { font-family: 'Arial', sans-serif; margin: 0; padding: 0; background-color: #f8f9fa; color: #444f5a; } /* 主容器 */ .dna-container { max-width: 1000px; margin: 40px auto; padding: 30px; background-color: #F4FFF8; border-radius: 8px; box-shadow: 0 4px 12px rgba(0, 0, 0, 0.1); text-align: center; } /* 标题样式 */ .dna-title { color: #4D4847; font-size: 28px; font-weight: bold; margin-bottom: 20px; text-align: center; position: relative; padding-bottom: 15px; } .dna-title:after { content: ""; position: absolute; bottom: 0; left: 50%; transform: translateX(-50%); width: 80px; height: 3px; background-color: #4D4847; } /* 正文段落，仅影响 p 标签 */ p.dna-content { font-size: 16px; line-height: 1.6; margin: 0 auto 30px; color: #4D4847; max-width: 800px; text-align: center; } /* 表格内文字颜色不受 .dna-content 段落控制 */ .dna-content table, .dna-content th, .dna-content td { color: initial; } /* 按钮样式 */ .learn-more-btn { display: inline-block; padding: 12px 30px; background-color: #52616b; color: white; text-decoration: none; font-weight: bold; border-radius: 4px; transition: all 0.3s ease; text-transform: uppercase; letter-spacing: 1px; font-size: 14px; border: 2px solid #ffffff; cursor: pointer; } .learn-more-btn:hover { background-color: transparent; color: #0066cc; border-color: #52616b; } /* 响应式设计 */ @media (max-width: 768px) { .dna-container { margin: 20px; padding: 20px; } .dna-title { font-size: 24px; } p.dna-content { font-size: 15px; max-width: 100%; } } JTSPEEDWORK Maintenance Plans. Protect your JTSPEEDWORK devices for constant peak performance with these recommended maintenance plans. Device uptime, confidence, and savings — that's what you get with JTSPEEDWORK maintenance plans. You protect business-critical devices and eliminate disruptions and unplanned repair expenses. LEARN MORE

Description: JT-1292 is a high-performance single-channel integrated RFID reader. Using self-developed high-performance RFID modules based on Impinj E710 chip, and working together with integrated awesome 12dBi linear polarized antenna. The reader supports RS232, RJ45 ,WiFi,4 GPRS communication interfaces. The whole series of products have a unified protocol and SDK.You only need to develop our products once to connect with all our RFID readers.JT-1292 is applicable widely in warehousing, archives management, library management, banking, production line management and other fields. Feature: Support RS232, RJ45,WiFi,4G remote online firmware upgrade Support MQTT protocol Item No. JT-1292 Physical parameters Antenna Dimensions 450(L)*450(W)*50(H)mm 12dBi linear polarized antenna Net weight 4.5kg Material ABS & aluminum alloy Power Supply Operate voltage 9-36V RFID parameters Operate current 0.65A@30dBm,25° C Air Protocol Power adapter DC 12V/3A EPC global Gen2(ISO18000-6C) Working frequency User Environment 865-868 / 920-925 / 902-928 MHz ( custom-design for frequency band ) Operating Temp. -40 ℃ to 75 ℃ RFID chip Storage Temp. -45 ℃ to 80℃ Impinj E710 Humidity 5-90% non-condensing (+25° C ) RF power 13~33dBm(adjustable) Reading Performance Reading rate Reading distance >900 times/sec Up to 30m(relate to tag and environment) RSSI Model Type Support JT-1292B RS232,TCP/IP(PoE optional) Work mode JT-1292W RS232,TCP/IP,Wi-Fi Master-slave, timing,trigger mode JT-1292G RS232,TCP/IP,4 GPRS Consumption Datasheet Average power consumption<9W Notification SDK LED indicator,buzzer C# , Java , C++ JTSPEEDWORK Maintenance Plans. /* 全局样式 */ body { font-family: 'Arial', sans-serif; margin: 0; padding: 0; background-color: #f8f9fa; color: #444f5a; } /* 主容器 */ .dna-container { max-width: 1000px; margin: 40px auto; padding: 30px; background-color: #F4FFF8; border-radius: 8px; box-shadow: 0 4px 12px rgba(0, 0, 0, 0.1); text-align: center; } /* 标题样式 */ .dna-title { color: #4D4847; font-size: 28px; font-weight: bold; margin-bottom: 20px; text-align: center; position: relative; padding-bottom: 15px; } .dna-title:after { content: ""; position: absolute; bottom: 0; left: 50%; transform: translateX(-50%); width: 80px; height: 3px; background-color: #4D4847; } /* 正文段落，仅影响 p 标签 */ p.dna-content { font-size: 16px; line-height: 1.6; margin: 0 auto 30px; color: #4D4847; max-width: 800px; text-align: center; } /* 表格内文字颜色不受 .dna-content 段落控制 */ .dna-content table, .dna-content th, .dna-content td { color: initial; } /* 按钮样式 */ .learn-more-btn { display: inline-block; padding: 12px 30px; background-color: #52616b; color: white; text-decoration: none; font-weight: bold; border-radius: 4px; transition: all 0.3s ease; text-transform: uppercase; letter-spacing: 1px; font-size: 14px; border: 2px solid #ffffff; cursor: pointer; } .learn-more-btn:hover { background-color: transparent; color: #0066cc; border-color: #52616b; } /* 响应式设计 */ @media (max-width: 768px) { .dna-container { margin: 20px; padding: 20px; } .dna-title { font-size: 24px; } p.dna-content { font-size: 15px; max-width: 100%; } } JTSPEEDWORK Maintenance Plans. Protect your JTSPEEDWORK devices for constant peak performance with these recommended maintenance plans. Device uptime, confidence, and savings — that's what you get with JTSPEEDWORK maintenance plans. You protect business-critical devices and eliminate disruptions and unplanned repair expenses. LEARN MORE

JT-SC12 Rfid Locker Lock Cabinet Tools Key Smart Sunpln Industrial Color Storage Takeaway Bullet Home Door Outdoors System

JT-7424 can package into wet inlay, standard card or the other heterotypic tags, achieving the needs of industry, and application. It is convenient to stick with the characteristics that are widely applied to aviation, warehousing, retail, clothing, medical, anti-counterfeiting and other fields.

This UHF PCB Anti-metal Tag  is widely used in indoor asset management, inspection management, and tool management.UHF RF4 PCB On metal Passive RFID tags are designed and produced by special technology and process, for indoor and outdoor usage in harsh industrial environment.

Size: 65*5*1.26mm; Chip: NXP Ucode 8; Flexible UHF RFID On-metal Tag.

2.4GHz RFID reader. Data transmission module with integrity structure and full-function. It includes RF Module,central control unit, input/output ports, Ethernet module, serial communication interface, non-volatile memory modules and working status indication module and built-in antenna etc.
