Brand:
JTSPEEDWORKItem NO.:
JT-971Operating system
Android 11.0Working frequency:
860-960MHzProtocol:
ISO18000-6C
| Physical Characteristics | Communication | |||
| Dimensions | 164.2 x 78.8 x 17.5mm / 6.46 x 3.10 x 0.69 in. | WLAN | IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna | |
| Weight | ＜321 g / 11.32 oz. | WWAN | 2G: GSM850/GSM900/DCS1800/PCS1900 | |
| Display | 5.2'' IPS LTPS 1920 x 1080 | 3G: WCDMA：B1/B2/B4/B5/B8 | ||
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported | CDMA2000 EVDO: BC0 | ||
| Power | Main battery: Li-ion, rechargeable, 5000 mAh | TD-SCDMA：A/F | ||
| Standby: over 350 hours | 4G:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A | |||
| Continuous use: over 12 hours (depending on user environment) | B28B/B34/B38/B39/B40/B41 | |||
| Charging time: 3-4 hours (with standard adaptor and USB cable) | WWAN (Others) | Depending on the country's ISP | ||
| Notification | Sound, LED indicator, vibrator | Bluetooth | Bluetooth 5.0 | |
| Expansion Slot | 1 slot for Nano SIM card, 1 slot for Nano SIM or TF card | GNSS | GPS/AGPS, GLONASS, BeiDou; internal antenna | |
| Interfaces | USB 2.0 Type-C, OTG, Type-C headphones supported | Note | C71 models being manufactured for Turkish & Egyptian Markets, do not include Voice Call ( Phone Call ) function. WAN module included on those models only support DATA transfer. | |
| Audio | 2 microphones，1 for noise cancellation；1 speaker；receiver | |||
| Keypad | 4 front keys, 1 power key, 2 scan keys, 1 multifunctional key | |||
| Sensors | Light sensor, proximity sensor, gravity sensor | |||
| Developing Environment | Performance | |||
| Operating System | Android 11.0; GMS, FOTA, Soti MobiControl, SafeUEM supported. Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility | CPU | Cortex-A53 2.3 GHz Octa-core | |
| SDK | Software Development Kit | RAM+ROM | 3GB + 32GB | |
| Language | Java | 4GB + 64GB (optional) | ||
| Tool | Eclipse / Android Studio | Expansion | Supports up to 128 GB Micro SD card | |
| User Environment | Barcode Scanning | |||
| Operating Temp. | 4 °F to 122 °F / -20 °C to 50 °C | 1D Linear Scanner | Zebra: SE965; Honeywell: N4313 | |
| Storage Temp. | -40 °F to 158 °F / -40 °C to 70 °C | 2D Imager Scanner | Zebra: SE4710 / SE4750SR / SE4750MR / SE4750DP; Honeywell: N6603 | |
| Humidity | 5% RH - 95% RH non condensing | 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. | |
| Drop Specification | Multiple 1.8 m / 5.9 ft. drops (at least 20 times) to the concrete across the operating temperature range | 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc. | |
| Tumble Specification | 1000 x 0.5 m / 1.64 ft. falls at room temperature | Note | * This function is optional | |
| Sealing | IP65 / IP67 per IEC sealing specifications | |||
| ESD | ±15 KV air discharge, ±6 KV conductive discharge | |||
| Note | * Operating temperature of UHF version: -20°C to 45°C | |||
| UHF RFID | Camera | |||
| Engine | Impinj E310 | Front Camera | 5 MP | |
| Frequency | 865-868 MHz / 920-925 MHz / 902-928 MHz | *This function is optional | ||
| Protocol | EPC C1 GEN2 / ISO18000-6C | Rear Camera | 13 MP autofocus rear camera with flash | |
| Antenna | Circular polarization (1.5 dBi) | NFC | ||
| Power | 1W (+19 dBm to +30 dBm adjustable) | Frequency | 13.56 MHz | |
| Max Read Range | Impinj E310 chip: | Protocol | ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. | |
| 3m (Impinj MR6 tag, size 70 x 15mm) | Chips | M1 card (S50, S70), CPU card, NFC tags, etc. | ||
| 3m (Impinj M750 tag, size 70 x 15mm) | Range | 2-4 cm | ||
| 4m (Alien H3 Anti-Metal tag, size 130 x 42mm) | ||||
| Note | * Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment. | |||
