WIFI UHF Middle Range Reader 6M

WIFI UHF Middle Range Reader 6M

RFID middle range reader JT-8280W could be applied in various harsh working environment for multiple protocol compatible and reading fast. Full support the tag of ISO-18000-6C or ISO-18000-6B. Its stable reading distance is 6m(related to the tag and environment). JT-8280W is easier to install for its small size and light weight.

  • Brand:

    JTSPEEDWORK
  • Item NO.:

    JT-8280W
  • Payment:

    100% TT in advance
  • Product Origin:

    China
  • Lead Time:

    Within 3-7 Days
product details

Application:

1.Intelligent traffic such as ETC;

2. Customs border-crossing;

3. Parking lot ;

4. Automatic weighting;

5. Container management,pallet management ;

6. Asset management ;

7. Ticketing& access control;

8. Pharmaceuticals such as medical waste management.


Specification:

Item No


JT-8280W

RS232,WIFI,Wiegand

Performance parameters


Working Frequency

902~928 MHz or 865~868MHz

Protocol

ISO18000-6C(EPC C1 GEN2)

Radio frequency power

0dBm~30dBm(Adjustable)

Software & SDK

DEMO and C#,VC,VB,Java,DELPHI, etc.,

Encryption

Can be directly encrypted, copy prevention.

Reading range

stable reading range 6M(Depends on tag&environment)

Industrial lightning protection

6000V industrial lightning protection

Low temperature protection

Northeast,Northwest extremely cold region,low temperature protection

Frequency modulation way

Broad spectrum frequency hopping or fixed frequency

Input/output port

Two-way relay output(customized), one-way trigger input

Antenna gain

8dBi circular polarization

Working way

Buzzer

Power

12V/3A Adaptor

Physical parameters:


Item size

220x220x50mm

Package size

430x320x140mm

Net weight

3KG

Shell material

ABS

Working temperature

-20℃~+65℃

Storage temperature

-45℃~+95℃



Leave A Message

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
