Brand:
JTSPEEDWORKItem NO.:
JT-K4026Order(MOQ):
1Payment:
100% TT in advanceProduct Origin:
ChinaShipping Port:
ShenzhenLead Time：
5 working days
| Performance Parameters | |
| RFID Protocol: | EPC Class1 Gen2, ISO18000-6C |
| Frequency: | (US) 902-928MHz, (EU) 865-868MHz |
| Chip: | NXP UCODE 8 |
| Storage: | EPC 128bits , User 32bits, TID 96bits |
| Rewrite times: | 100000 |
| Func: | Read/Write |
| Data preservation: | 50 years |
| Reading distance(handheld reader): | 1-1.5M,mounted on metal surface(The reading distance varies according to different readers) |
| Application: | Intelligent warehouse management, pallet management, industrial manufacturing. |
| Physical Parameters | |
| Size: | L:40mm*W:25.9*T:6.5mm |
| Material: | Stainless steel,potting |
| Color: | Gold/Natural Color |
| Install method: | Locking screws, adhesive, riveting |
| Weight: | 14.2g |
| Environmental Parameters | |
| IP Level: | IP68 |
| Storage temperature: | -20℃ - +80℃ |
| Working temperature: | -20℃-+180℃ |
| Material properties | High and low temperature resistance, wear resistance, anti aging, can withstand high weight impact |
| Tolerable gravity | 3 tons of collision avoidance |
