Brand:
JTSPEEDWORKItem NO.:
JT-982Communication Interface
BluetoothWorking frequency:
860-960MHzProtocol:
ISO18000-6CRF chip:
Impinj E710Antenna gain:
4dBi
Physical Characteristics | UHF RFID | |||
Dimensions | 282 x 117.5 x 32mm / 11.10 x 4.63 x 1.26in. | Engine | Impinj E710 | |
Weight | 334 g / 11.78oz. (with battery) | Impinj Indy R2000 | ||
Display | 1.77 inch, 128 x 160 | Frequency | 920-925MHz / 902-928MHz / 865-868MHz | |
Power | Battery specification: 5200 mAh | Antenna | Linear Polarized antenna (4dBi) | |
Standby: over 70 hours (keeping bluetooth connected) | Fastest Read Rate | 900+ tags/sec | ||
Continuous use: up to 6 hours (UHF reading) | Max Read Range | Impinj E710 chip: | ||
Charging time: 3-4 hours (with standard adaptor and USB cable) | 26m (Impinj MR6 tag, size 70 x 15mm) | |||
Buzzer | Support | 27m (Impinj M750 tag, size 70 x 15mm) | ||
Interfaces | Micro-USB | 31m (Alien H3 Anti-Metal tag, size 130 x 42mm) | ||
Indicator LED | Power, Work, Bluetooth | |||
Product Material | Plastic | Impinj R2000 chip: | ||
Colour | White | 22m (Impinj MR6 tag, size 70 x 15mm) | ||
23m (Impinj M750 tag, size 70 x 15mm) | ||||
22m (Alian H3 Anti-Metal tag, size 130 x 42mm) | ||||
Note | * Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment. | |||
User Environment | Barcode Scanning | |||
Operating Temp. | -20℃~+50℃ | 2D Imager Scanner | SE2707 | |
Storage Temp. | -40℃~+70℃ | 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. | |
Humidity | 5%RH - 95%RH non condensing | 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc. | |
Drop Specification | Multiple 1.5m / 4.9ft. drops (at least 20 times) to the concrete across the operating temperature range | Note | *This function is optional | |
Tumble Specification | 1000 x 0.5m / 1.64ft. falls at room temperature | Communication | ||
ESD | ±15KV air discharge, ±8KV conductive discharge | Bluetooth | Bluetooth Low Energy (BLE) 4.0 | |
Developing Environment | Performance | |||
SDK | Android / iOS | MCU | Cortex-M3 | |
Language | Java / Objective-C | 72MHz | ||
Tool | Android Studio / Xcode | Storage | 50000 tags |
